NET RADIOMETER NR LITE THIES
Ref : 7.1415.40.000
Availability: Out of stock
Electr. Output : -25-24 mV Measuring range : -2000-2000 W/m² Spectral range : 200-100000nm
Reference: 7.1415.10.000
NET RADIATION TRANSMITTER THIES
Contact us
Electr. Output : 0-18 mV Measuring range : -300-1500 W/m² Spectral range : 300-100000nm
For the direct measurement of the net radiation in the short-wave and long-wave range. Two identical contra-connected thermopiles measure the global- and the reflex-radiation; they output the difference as measuring value.The instrument comes up to “First Class” acc. to WMO.
Delivery includes calibration certificate.
More information : Our website BLET
7.1415.10.000
Data sheet
- Précision
- 2%
- Résolution
- 15 µV/W/m²
- Matériau(x)
- Lupolene
- Plage de mesure
- -300-1500 W/m²
- 1 - Type de produit
- Capteur de radiation net
- Connexion electr.
- Cable 10m
- Domaine spectral
- 300-100000nm
- Sortie
- 0-18 mV
- Dimensions
- 127x50x35mm
Electr. Output : 0-18 mV Measuring range : -300-1500 W/m² Spectral range : 300-100000nm
